Serie Minidrel 90B_MSR

МОБИЛЬНЫЕ КРАНЫ для обработки пресс-форм и пневматического производства. До 9.000 Кг. груза.

Они могут использоваться во внутренних помещениях, таких как промышленные.

ЗАПРОСИТЬ ПРЕДЛОЖЕНИЕ

Весь ассортимент оборудования Gruniverpal сертифицирован в соответствии со следующими международными стандартами. ЗАПРОСИТЬ ПРЕДЛОЖЕНИЕ


Standard min. hook's height from the ground	100 mm
Standard max. hook's height from the ground	5.800 mm
Standard max. telescopic extension	4.900 mm
Capacity at max.telescopic extension (point 7)	-
Rotation (option)	-
Wheelbase	2.900 mm
Dimensions- lenght	3.810 mm
Dimensions- width	1.500 mm
Dimensions- height	2.650 mm
Adjustable speed from / to	From 0 to 100 m/min
Max. surmountable slope ( unloaded )	16%
Max. surmountable slope ( loaded )	8%
Front wheels	2 x ø 533 x 230 mm
Rear driving wheel	2 x ø 533 x 178 mm
Wheels material	Cushion
Drive	FOUR WHEELS
Electric motor power	10,0 KW / 48 cc.
Hardened battery (standard)	660 Ah / 48V
Battery charger on board	380 /440 V -50/60 Hz
Lead acid battery	●
Gel battery	○
Additional autonomy of battery	○
Proportional control on board of all mouvements	●
Certification to standard 2006/42 CE	●
Made in accordance (not certified) to standard UL508 A	●
Certification (issued by Third Party) to standard UL508 A	○
Drive hydraulic unit	●
Automatic braking system	●
Overloading safety system	●
Pressure safety valves on each movements	●
Safety emergency electric devices	●
Winch (lifting capacity on demand)	○
Wireless remote control (capacity on demand)	○
User Manual and technical documentation	●
Possibility to do all movements with max. Load	●
