Serie GB 100

Краны для обработки пресс-форм и пневматического производства.

До 100 Кг. груза.

Они могут использоваться во внутренних помещениях, таких как промышленные.

ЗАПРОСИТЬ ПРЕДЛОЖЕНИЕ

Весь ассортимент оборудования Gruniverpal сертифицирован в соответствии со следующими международными стандартами. ЗАПРОСИТЬ ПРЕДЛОЖЕНИЕ


Standard min. hook's height from the ground	500 mm
Standard max. hook's height from the ground	2.600 mm
Standard max. telescopic extension	1.500 mm
Capacity at max.telescopic extension (point 7)	-
Rotation (option)	-
Wheelbase	1.000 mm
Dimensions- lenght	1.560 mm
Dimensions- width	820 mm
Dimensions- height	1.470 mm
Adjustable speed from / to	From 0 to 40 m/min
Max. surmountable slope ( unloaded )	3%
Max. surmountable slope ( loaded )	3%
Front wheels	4 x Ø 160 x 60 mm
Rear driving wheel	-
Wheels material	Polyurethane
Drive	-
Total weight:	375 kg
Electric motor power	0,6 KW /12V
Hardened battery (standard)	100 Ah / 12 V
Battery charger on board	110 / 240 V -50/60 Hz
Lead acid battery	-
Gel battery	●
Additional autonomy of battery	-
Proportional control on board of all mouvements	●
Certification to standard 2006/42 CE	●
Made in accordance (not certified) to standard UL508 A	-
Certification (issued by Third Party) to standard UL508 A	-
Drive hydraulic unit	-
Automatic braking system	-
Overloading safety system	●
Pressure safety valves on each movements	●
Safety emergency electric devices	●
Winch (lifting capacity on demand)	-
Wireless remote control (capacity on demand)	-
User Manual and technical documentation	●
Possibility to do all movements with max. Load	●
